PTZ Camera HDMI USB SDI 4k ptz conference camera 12x all in one design

Product Categories

Yisen technology camera Co, LTD

Contact Now

Name: PTZ Camera HDMI USB SDI 4k ptz conference camera 12x all in one design
Brand: Yisen
Price: 1 USD

Brand Name : Yisen

Model Number : FT-camera23

Certification : CE ROHS

Place of Origin : Guangdong China

MOQ : 1pcs

Payment Terms : T/T, Western Union, MoneyGram paypol

Supply Ability : 2000pcs

Delivery Time : 2-6 work days

Packaging Details : standard carton box with thick pearl cotton

Digital Zoom : 16x

HD Output : 1xHDMI: Version 2.0

USB Interface : 1xUSB3.0, Type-B 1xUSB2.0, Type-A

Contact Now

Close-up Camera
Video System	4K@30/25/29.97, 1080p/60/50/30/59.94/29.97, 1080i/60/50/59.94, 720p/60/59.94
Sensor	1/2.5'', CMOS, Effective Pixel: 8.51M
Scanning Mode	Progressive
Lens	12x, f4.4mm ~ 52.8mm, F1.8 ~ F2.6
Digital Zoom	16x
Panorama Camera
Video System	4K@30/25/29.97, 1080p/60/50/30/59.94/29.97, 1080i/60/50/59.94, 720p/60/59.94
Sensor	1/2.5'', CMOS, Effective Pixel: 8.51M
Scanning Mode	Progressive
Lens Mount	M12 Mount
Teacher Panorama Lens	f=8.0mm, AoV about 42°(default, changeable)
Student Panorama Lens	f=3.24mm, AoV about 84° (default, changeable)
Input/Output Interface
HD Output	1xHDMI: Version 2.0
HD Output	1x3G-SDI: BNC type, 800mVp-p, 75Ω, Along to SMPTE 424M standard
Network Interface	1xRJ45: 10M/100M/1000M Ethernet Interface, POE supported
Audio Interface	1-ch: 3.5mm Audio Interface, Line In
USB Interface	1xUSB3.0, Type-B 1xUSB2.0, Type-A
Communication Interface	1xRS232 In: 8pin Min DIN, Max Distance: 30m, VISCA/Pelco-D/Pelco-P Protocol
	1xRS232 Out: 8pin Min DIN, Max Distance: 30m
	1xRS485: 2pin Phoenix Port, Max Distance: 1200m, Protocol: VISCA/Pelco-D/Pelco-P
Power Jack	DC-005/Φ2.0 type (DC IN 12V)

PTZ Camera HDMI USB SDI 4k ptz conference camera 12x all in one design
